Apple iMac G5 (17-inch, Ambient Light Sensor) vs Apple iMac Pro (2017)

Every spec side by side, from each maker's published figures.

Only show differences

Better figure, where one is clearly better

Share comparison

iMac G5 (17-inch, Ambient Light Sensor) compared with iMac Pro (2017)

	AppleiMac G5 (17-inch, Ambient Light Sensor)	AppleiMac Pro (2017)
Overview
Released
Released	May 2005	December 2017
Performance
Processor
Processor	IBM PowerPC G5 1.8 GHz (iMac Ambient Light Sensor) or IBM PowerPC G5 2 GHz (iMac Ambient Light Sensor)	Intel Xeon W-2140B, Intel Xeon W-2150B, Intel Xeon W-2170B or Intel Xeon W-2191B
CPU cores
CPU cores	1	8, 10, 14 or 18
Graphics
Graphics	ATI Radeon 9600 (128 MB)	Radeon Pro Vega 56 (8 GB HBM2), Radeon Pro Vega 64 (16 GB HBM2) or Radeon Pro Vega 64X (16 GB HBM2)
Memory
Memory	512 MB or 2 GB	32 GB, 64 GB, 128 GB or 256 GB (better)
Storage
Storage	160 GB to 400 GB	1 TB to 4 TB (better)
CPU
CPU	1.8 GHz PowerPC G5 with 600 MHz frontside bus and Combo drive, or 2.0 GHz with 667 MHz bus and SuperDrive; both have 512 KB L2 cache. Generic maker-clock chip records retain the single-core identity cross-checked with exact EveryMac sources; uncertain 970/970FX silicon revision is not inferred.	Xeon W at 3.2 GHz with 8 cores (Turbo Boost 4.2 GHz), 3.0 GHz with 10 cores (4.5 GHz), 2.5 GHz with 14 cores (4.3 GHz) or 2.3 GHz with 18 cores (4.3 GHz). Exact W-B CPU identities follow Geekbench. The 8/10-core versions launched first; Macworld reports later January 2018 availability for 14/18-core options. Apple changed the standard configuration to 10 cores in August 2020.
GPU
GPU	ATI Radeon 9600 with 128 MB dedicated video memory; AGP 8x support.	Radeon Pro Vega 56 with 8 GB HBM2, optionally Vega 64 or Vega 64X with 16 GB HBM2. Vega 64X is a later option included in Apple’s current specification sheet, absent from the launch reviews.
Memory type
Memory type	400 MHz DDR SDRAM (PC3200), two 184-pin DIMM slots; 512 MB standard and 2 GB supported maximum. Configurations conservatively list the published base and maximum; no intermediate factory pairing is inferred.	Quad-channel 2666 MHz DDR4 ECC; 32 GB standard, configurable to 64/128/256 GB. The current maker sheet includes the later 256 GB option; launch reviews cover up to 128 GB. No user-accessible memory door.
Storage type
Storage type	160 GB 7200 rpm Serial ATA hard drive, configurable to 250 or 400 GB. The 1.8 GHz base has a Combo drive (DVD reading/CD writing); the 2.0 GHz base has an 8x SuperDrive with 2.4x double-layer DVD writing.	1 TB SSD, configurable to 2 or 4 TB
Display
Screen size
Screen size	17″	27″
Resolution
Resolution	1440 × 900	5120 × 2880 (better)
Panel
Panel	–	IPS LCD
Brightness
Brightness	–	500 nits
Display type
Display type	Widescreen LCD with millions of colours; panel technology, refresh rate and brightness not published in the retained exact maker specification.	LED-backlit Retina 5K display; IPS panel confirmed by EveryMac. Native refresh rate omitted because Apple does not publish it in the specification sheet.
Display features
Display features	–	Wide colour (P3); supports one billion colours
Connections
Ports
Ports	3 × USB-A, Ethernet, headphone jack	4 × Thunderbolt 3, 4 × USB-A, SD card slot, Ethernet, headphone jack
Ethernet
Ethernet	1 Gb/s	10 Gb/s (better)
External displays
External displays	–	Up to 4
Wi-Fi
Wi-Fi	802.11g	802.11ac
Bluetooth
Bluetooth	2.0 + EDR	5.0
Camera
Camera	–	1080p FaceTime HD
Back ports
Back ports	Three USB 2.0 ports on the computer, plus two USB 1.1 ports on the keyboard; two FireWire 400 ports, Mini-VGA output, Gigabit Ethernet, headphone/optical output and audio line-in. Built-in 56K V.92 modem is confirmed by launch press and exact manual; retained USB-HSP wording describes its internal transport, rather than an extra external USB device.	Four USB-A ports; four Thunderbolt 3 USB-C ports with DisplayPort 1.2, Thunderbolt up to 40 Gb/s and USB 3.1 Gen 2 up to 10 Gb/s; UHS-II SDXC, Nbase-T Ethernet supporting 1/2.5/5/10Gb and 3.5 mm headphone jack. Thunderbolt 2, HDMI, DVI and VGA require adapters.
External displays
External displays	Optional Mini-VGA adapters provide VGA, S-video or composite output; no DVI connector is listed.	Two 5120 × 2880 displays at 60 Hz with one billion colours, four 3840 × 2160 displays at 60 Hz with one billion colours, or four 4096 × 2304 displays at 60 Hz with millions of colours, alongside the built-in display
Speakers
Speakers	Built-in stereo speakers and microphone.	Stereo speakers
Microphones
Microphones	–	Four microphones; supports Hey Siri
Keyboard and mouse
Keyboard and mouse	Apple Keyboard and Apple Mouse; the later Mighty Mouse and iSight-generation remote are not substituted for the launch accessories.	Space grey Magic Keyboard with Numeric Keypad and Magic Mouse 2; optional space grey Magic Trackpad 2
Design and power
Type
Type	All-in-one	All-in-one
Weight
Weight	8.4 kg (better)	9.7 kg
Width × depth × height
Width × depth × height	426 × 173 × 430 mm	650 × 203 × 516 mm
Operating system
Operating system	macOS	macOS
Size and weight detail
Size and weight detail	–	Dimensions include the stand; weight varies by configuration and manufacturing process. Optional VESA mount adapter kit.
Power supply
Power supply	–	100–240 V AC, 50–60 Hz, single phase
Materials
Materials	–	Recyclable aluminium enclosure; arsenic-free glass and mercury-free LED backlight
In the box
In the box	iMac G5, keyboard, mouse, power cord, install/restore DVDs and documentation; Mac OS X Tiger, iLife ’05 and AppleWorks. Classic support is available but not preinstalled and cannot boot Mac OS 9.	iMac Pro, space grey Magic Keyboard with Numeric Keypad, space grey Magic Mouse 2, Lightning to USB cable and power lead
