Power Macintosh 7100/80AV

Released 1995

An 80 MHz PowerPC desktop with S-video capture, two display outputs and three NuBus slots.

Product links

Processor: PowerPC 601 80 MHz (Power Macintosh 7100/80AV)
CPU cores: 1
Memory: 16 MB
Storage: 350 MB to 700 MB
CPU: 80 MHz PowerPC 601 with integrated floating-point unit, 32 KB L1 cache, 256 KB L2 cache and 64-bit data path at 40 MHz; 4 MB ROM
GPU: AV video card with 2 MB VRAM, plus separate HDI-45 video using system DRAM. Unlike the non-AV model's expandable video card, AV video memory is fixed.
Memory type: Japanese bundles have 16 MB including 8 MB soldered to the logic board; four 72-pin noncomposite 80 ns SIMM sockets accept matched pairs, up to 136 MB total. English support lists an 8 MB minimum.
Storage type: Japanese exact-model bundles have 350 MB or 700 MB internal SCSI hard drives, 1.44 MB Apple SuperDrive floppy and 2× AppleCD 300i Plus CD-ROM. The December 1994 US brochure's M3645LL/A AV bundle has 16 MB RAM, a 700 MB hard drive and CD-ROM.
Expansion slots: Three NuBus slots; processor-direct slot occupied by the AV card. Internal bay accommodates one half-height 5.25-inch device such as the CD-ROM drive.

Ports: Ethernet
External displays: Up to 2
Back ports: ADB, AAUI-15 Ethernet, HDI-45 and DB-15 video, external DB-25 SCSI, two LocalTalk/GeoPort serial ports, 16-bit stereo audio input and output, S-video input and output with composite adapters, and DAV connector
External displays: Two simultaneous displays using DRAM and AV-card outputs. AV VRAM supports 24-bit colour at 640 × 480 and 832 × 624, or 16-bit colour at 1024 × 768 and 1152 × 870. Only one monitor or television can be attached to the AV card at a time.
Keyboard and mouse: Japanese bundles include Apple Desktop Bus Mouse II and composite video adapters; keyboard and monitor sold separately. US brochure also includes two composite video adapters and lists a PlainTalk microphone.

Type: Compact
Weight: 11.3 kg
Width × depth × height: 330 × 419 × 152 mm
Operating system: macOS
Size and weight detail: Japanese exact-model page publishes 152 × 330 × 419 mm and 11.3 kg, varying with installed devices; original brochure gives the same metric dimensions and weight
Power supply: Automatically configured 100–240 V AC, 50–60 Hz; Japanese exact-model page and Service Source give 167 W maximum continuous and 230 W peak input, excluding the monitor, with 112 W continuous DC output in Service Source. The December 1994 US brochure instead lists 325 W maximum, while English support lists 230 W; those different conditions remain qualified.
In the box: Japanese bundles include power cable, KanjiTalk 7.5 CD-ROM, manuals and warranty. English support lists original System 7.5 with PowerPC Enabler 1.1.1 and introduction on 3 January 1995. April 1995 AppleFacts lists the 7100/80 as currently offered with an AV configuration; release year 1995 retained, with first-sale month unresolved.

Processor	Memory	Storage	Storage type
PowerPC 601 80 MHz (Power Macintosh 7100/80AV)	16 MB	350 MB	Hard drive
PowerPC 601 80 MHz (Power Macintosh 7100/80AV)	16 MB	700 MB	Hard drive
