OnePlus OnePlus Ace 5 Pro
Photo 1 of 8

OnePlus OnePlus Ace 5 Pro · Photo source

OnePlus · Ace

OnePlus Ace 5 Pro

Released December 2024

A Chinese gaming phone with Snapdragon 8 Elite, a 6.78-inch 1–120 Hz LTPO OLED display and 100 W wired charging. Its dual-cell battery has a 6,100 mAh equivalent typical capacity; glass and ceramic finishes have different weights.

Screen
6.78″
Display
LTPO OLED, 120 Hz
Chip
Qualcomm Snapdragon 8 Elite
Memory
12 GB – 16 GB
Storage
256 GB – 1 TB
Main camera
50 MP
Zoom
–
Battery
6,100 mAh
Weight
203 g

What reviewers say

ZOL and AnTuTu praised sustained gaming performance, comfortable construction and useful main-camera results. Both found fast charging, and ZOL reported strong battery endurance. Thermal findings varied: ZOL found little heat in its gaming tests, while AnTuTu’s enhanced 120 fps Genshin test reached noticeably higher temperatures. These are dated tests with different games, settings and finishes.

From mobile.zol.com.cn and antutu.com

Specifications

Report a wrong or missing spec

Display

Screen size
6.78″
Resolution
2780 × 1264
Sharpness
450 pixels per inch
Panel
LTPO OLED
Refresh rate
120 Hz
Peak brightness
4,500 nits
Display type
Flat 8T LTPO OLED (maker overview), 1–120 Hz adaptive refresh; 93.9% screen-to-body ratio and 10-bit colour
Pixel density
450 ppi
Brightness detail
Maker typical maximum 800 nits normal full-screen, 1,600 nits triggered full-screen and 4,500 nits peak; peak is a separate condition
Screen protection
OPPO Crystal Shield glass
Display features
100% DCI-P3 in listed colour modes; always-on display and local adaptive refresh. 2160 Hz PWM with three-pulse or one-pulse dimming and an alternative DC-like mode. X2 luminous material and Display P2 chip; overview shows Dolby Vision, HDR10+, ZREAL and HDR Vivid

Performance

Chip
Qualcomm Snapdragon 8 Elite
Memory
12 GB – 16 GB
Storage
256 GB, 512 GB, 1 TB
CPU
3 nm, eight cores (two prime and six performance); specification table rounds maximum to 4.3 GHz while overview states 4.32 GHz
GPU
Adreno 830 at 1.1 GHz
Memory
12 or 16 GB LPDDR5X; ZOL’s LPDDR5T wording differs from exact maker specification
Storage type
UFS 4.0; 256 GB, 512 GB or 1 TB. Five published RAM/storage configurations; launch ceramic special edition offered 16/512 and 16/1024
Cooling
Maker 天工散热 Elite dual vapour-chamber construction with three-dimensional capillary channels, graphite and thermal gel. Overview explicitly distinguishes Ace 5 and Pro cooling; no standard-model VC area transferred

Cameras

Main camera
50 MP
Ultra wide camera
8 MP
Telephoto camera
None
Optical zoom
None
Front camera
16 MP
Main camera
50 MP Sony IMX906 (maker overview), f/1.8, 24 mm equivalent, six-element lens; autofocus, phase detection and two-axis OIS
Ultra wide camera
8 MP, f/2.2, 16 mm equivalent, five-element lens and 112° field of view; fixed focus
Front camera
16 MP, f/2.4, 24 mm equivalent, five-element lens and fixed focus; exact maker table does not identify sensor
Zoom
No optical zoom; up to 20× digital zoom
Video recording
4K or 1080p 30/60 fps; 720p 30 fps. Stabilisation at 4K/1080p 30/60 fps. Slow motion 1080p 240 fps or 720p 240/480 fps; cinema 4K 30, time-lapse 4K/1080p 30 and multi-view 1080p 30
Front video
1080p or 720p 30 fps with stabilisation; beauty processing enabled by default
Camera features
2 MP macro camera, f/2.4, 22 mm equivalent, three-element lens and fixed focus. Rear JPG/HEIF/RAW, front JPG/HEIF; single-colour-temperature LED flash and flicker sensor. Portrait, night, professional, panorama, long exposure, document, macro, tilt-shift and AI editing/live-photo modes

Battery and charging

Battery
6,100 mAh
Wired charging
Up to 100 W
Wireless charging
None
Battery life detail
Non-removable dual cells in series: 3,050 mAh at 7.66 V typical, equivalent to 6,100 mAh at 3.83 V; 23.37 Wh. Rated 2,970 mAh at 7.66 V, equivalent to 5,940 mAh at 3.83 V; 22.76 Wh. SUPERVOOC S management chip
Wired charging
Up to 100 W SUPERVOOC and 100 W UFCS with an OPPO-certified charger; other UFCS chargers limited to 33 W. Supplied adapter rated 100 W. Maker 1%-to-full claim approximately 35 minutes at battery/ambient 25±1°C, screen off, flight mode and background apps closed. AnTuTu’s January 2025 test: 5%-to-full in 33 minutes at 25°C. Gaming bypass power supported with original adapter at launch; wider-adapter OTA support was a maker promise, not verified here

Design

Type
Standard
Weight
203 g
Thickness
8.14 mm
Height × width
161.72 × 75.77 mm
Water and dust resistance
IP65
Materials
Aluminium-alloy frame; Crystal Shield front and purple/black glass backs. White Moon ceramic special edition has a ceramic back
Colours
星穹紫 (Starry Purple), 潜航黑 (Submarine Black), 白月瓷 (White Moon ceramic special edition); English descriptions translate Chinese names. Glass finishes approximately 203 g, ceramic approximately 217 g without protective film. Shared 8.14 mm thickness with maker configuration/manufacturing tolerance
Buttons
Three-position Alert Slider for silent, vibration or ringing
Water resistance detail
IP65 under GB/T 4208-2017 / IEC 60529; maker test uses 6.3 mm nozzle at 2.5–3 m, 12.5 L/min for at least three minutes, water/product difference ≤5°C. Wear can reduce protection; immersion damage excluded from warranty
Biometrics
In-display optical fingerprint reader
Sensors
Proximity, ambient light, colour temperature, compass, accelerometer, gyroscope and Hall sensors; infrared remote transmitter and X-axis linear motor
Speakers
Stereo speakers, OReality Audio
Microphones
Three microphones; maker overview includes directional recording and gaming voice-noise reduction

Software

Operating system
Android
Software at launch
Chinese ColorOS 15.0 based on Android; exact maker table does not state Android major version. First sale 31 December 2024 following 26 December announcement/preorders
AI features
Chinese ColorOS assistant, document/notes and voice-summary tools, live-photo/file sharing and virtual split-screen; supported applications/services vary
In the box
Phone, USB-A to USB-C cable, charger, SIM ejector, protective case and quick-start guide

Connectivity

Mobile network
GSM 850/900/1800; WCDMA 1/4/5/6/8/19; LTE FDD 1/3/4/5/8/18/19/26/28A/66 and TDD 34/38/39/40/41/42/48; 5G SA/NSA n1/n3/n5/n8/n28A/n38/n40/n41/n48/n66/n77/n78/n79/n80/n81/n83A/n84/n89. Exact Chinese list lacks LTE band 20
SIM
Dual nano-SIM; Chinese operator and dual-SIM VoLTE conditions apply
Wi-Fi
Wi-Fi 7/6/5 and a/b/g/n; 2.4/5.1/5.8 GHz, 2×2 MIMO, up to 160 MHz at 5 GHz and eight spatial-stream sounding MU-MIMO; WLAN display, tethering and simultaneous 2.4/5 GHz operation. Maker G1 gaming Wi-Fi hardware
Bluetooth
Bluetooth 5.4, BLE Audio; SBC, AAC, aptX, aptX HD, LDAC and LHDC 5.0
NFC
13.56 MHz reader/writer, HCE, embedded secure element and NFC-SIM in slot 1; Chinese transport/payment services vary
USB
USB-C, USB 2.0; standard USB-C earphones supported
Positioning
BeiDou B1I/B1C/B2a, GPS L1/L5, GLONASS G1, Galileo E1/E5a and QZSS L1/L5; assisted, WLAN and cellular positioning

Storage options

StorageMemory
256 GB12 GB
256 GB16 GB
512 GB12 GB
512 GB16 GB
1 TB16 GB

Pros and cons

Pros

  • 1–120 Hz LTPO OLED screen
  • 100 W charging and gaming bypass power
  • Stabilised 50 MP main camera

Cons

  • No optical telephoto camera
  • IP65 protects against jets, not immersion
  • USB 2.0 and Chinese software/network bands

Closest rivals

Model
ScreenDisplayChipMemoryStorageMain cameraZoomBatteryWeightReleased
XiaomiPOCO F6 Pro
6.67″OLED, 120 HzQualcomm Snapdragon 8 Gen 212 GB – 16 GB256 GB – 1 TB50 MP–5,000 mAh209 gMay 2024
HonorX9c
6.78″OLED, 120 HzQualcomm Snapdragon 6 Gen 18 GB – 12 GB256 GB – 512 GB108 MP–6,600 mAh189 gNov 2024
iQOONeo9 Pro
6.78″LTPO OLED, 144 HzQualcomm Snapdragon 8 Gen 28 GB – 12 GB128 GB – 256 GB50 MP–5,160 mAh190 gFeb 2024
