Apple eMac (ATI Graphics, 2003) vs Apple eMac (USB 2.0, 2004)

Every spec side by side, from each maker's published figures.

Better figure, where one is clearly better

AppleeMac (ATI Graphics, 2003)AppleeMac (USB 2.0, 2004)
Overview
ReleasedMay 2003April 2004
Performance
ProcessorPowerPC G4 0.8 GHz (eMac ATI Graphics) or PowerPC G4 1 GHz (eMac ATI Graphics)PowerPC G4 7447A (1.25 GHz)
CPU cores11
GraphicsATI Radeon 7500 (32 MB DDR)ATI Radeon 9200 (32 MB DDR)
Memory128 MB, 256 MB, 512 MB or 1 GB256 MB, 512 MB or 1 GB
Storage40 GB to 80 GB40 GB to 160 GB
CPU800 MHz or 1 GHz PowerPC G4 with Velocity Engine, 256 KB full-speed on-chip L2 cache and 133 MHz system bus. EveryMac's exact-model processor inventory identifies PowerPC 7445; Apple publishes the G4 family and clocks.1.25 GHz PowerPC G4 with Velocity Engine, 512 KB full-speed on-chip L2 cache and 167 MHz system bus. EveryMac identifies this generation's processor as PowerPC 7447A; Apple publishes the G4 family and clock speed.
GPUATI Radeon 7500 with AGP 4× support and 32 MB dedicated DDR video memoryATI Radeon 9200 with AGP 4× support and 32 MB dedicated DDR video memory
Memory type128 MB PC133 SDRAM standard with CD-ROM or Combo drives; 256 MB with SuperDrive. Two user-accessible 168-pin DIMM slots support Apple's 1 GB maximum using 128 MB, 256 MB or 512 MB DIMMs.256 MB PC2700 333 MHz DDR SDRAM standard; 512 MB and 1 GB order options. Two user-accessible 184-pin DIMM slots support the maker's 1 GB maximum using 256 MB or 512 MB DIMMs.
Storage type800 MHz CD-ROM model has a 40 GB Ultra ATA disk; 1 GHz Combo has 60 GB; 1 GHz SuperDrive has 80 GB. CD-ROM reads at 32×. Combo reads DVD at 8× and writes CD-R at 32×, CD-RW at 10×. SuperDrive writes DVD-R at 4×, CD-R at 16× and CD-RW at 8×. These are the generation's published base pairings; unspecified cross-configuration drives are not assumed.Combo version has a 40 GB Ultra ATA/100 drive; SuperDrive has 80 GB. Maker order options include 80 GB and 160 GB drives. Combo reads DVDs at 12×, writes CD-R at 32× and CD-RW at 10×. SuperDrive writes DVD-R at 8×, CD-R at 24× and CD-RW at 10×. This is not the later double-layer 2005 SuperDrive.
Display
Screen size17″17″
Resolution1280 × 9601280 × 960
PanelCRTCRT
Display typeFlat 17-inch CRT with 16-inch viewable area and 0.25 mm dot pitch. Five supported screen modes from 640 × 480 to 1280 × 960 are analogue CRT modes, not a fixed pixel matrix. External VGA timing figures are not substituted for internal display refresh.Flat 17-inch CRT with 16-inch viewable area and 0.25 mm dot pitch. Supported screen modes run from 640 × 480 to 1280 × 960; these are analogue CRT modes rather than a fixed pixel matrix. The external VGA timing table is not treated as a published internal CRT refresh specification.
Connections
Ports3 × USB-A, Ethernet, headphone jack3 × USB-A, Ethernet, headphone jack
Ethernet0.1 Gb/s0.1 Gb/s
Wi-FiOptional AirPort Extreme 802.11gOptional AirPort Extreme 802.11g / 802.11b
Back portsThree USB 1.1 ports on the computer, shared across two 12 Mbps controllers, plus two on the keyboard; two FireWire 400 ports sharing 8 W; mini-VGA; headphone and audio line-in; built-in 10/100BASE-T Ethernet and 56K V.92 modem. A D-Link USB Bluetooth adapter is an optional accessory; no built-in Bluetooth is specified.Three USB 2.0 ports on the computer and two USB 1.1 ports on the supplied keyboard; two FireWire 400 ports with 8 W shared power; mini-VGA; headphone and audio line-in jacks; 10/100BASE-T Ethernet; built-in 56K V.92 modem. Internal Bluetooth is a build-to-order option, with no version published in the exact sheet.
External displaysVGA display mirroring through an optional Apple VGA Display Adapter; S-video/composite through an optional Apple Video Adapter. Published VGA modes include 1280 × 960 at 75 Hz, 1024 × 768 up to 100 Hz and lower resolutions up to 120 Hz. Extended desktop is not supported.VGA video mirroring through an optional Apple VGA Display Adapter; S-video/composite output through an optional Apple Video Adapter. VGA modes include 1280 × 960 at 75 Hz, 1024 × 768 up to 100 Hz and lower resolutions up to 120 Hz. External displays show the same image as the built-in screen.
SpeakersIntegrated stereo system with internal 16 W digital amplifierIntegrated stereo speakers with an internal 16 W digital amplifier
MicrophonesBuilt-in microphoneBuilt-in microphone
Keyboard and mouseApple Keyboard, Apple Mouse and modem cable; optional Tilt and Swivel StandApple Keyboard, Apple Mouse and modem cable; optional Tilt and Swivel Stand
Design and power
TypeAll-in-oneAll-in-one
Weight22.7 kg22.7 kg
Width × depth × height406 × 433 × 406 mm406 × 433 × 406 mm
Operating systemmacOSmacOS
Size and weight detailMaker metric dimensions and reference weight retained. Weight varies with configuration and manufacturing process; published centimetre and inch values do not convert exactly.Apple's published metric dimensions and reference weight; weight varies with configuration and manufacturing process. Metric centimetres and imperial inches in the retained sheet do not convert exactly.
Power supplyConfigured for 100 V AC or 220 V AC according to country; 47–63 Hz, single phaseConfigured for 100–120 V AC or 200–240 V AC according to country; 50–60 Hz, single phase
Power useMaximum continuous electrical power 170 WMaximum continuous electrical power 230 W; distinct from the audio amplifier rating
ColoursWhiteWhite
In the boxMac OS X 10.2 Jaguar and iLife. Apple's exact footnote permits native Mac OS 9 startup only on CD-ROM and Combo configurations; all can run Mac OS 9 applications through Classic in Mac OS X. AirPort Extreme works only in Mac OS X. Apple confirmed immediate consumer sale on 6 May 2003.Launched with Mac OS X 10.3 Panther, Classic environment and iLife ’04. Apple's 13 April 2004 retail notice says the consumer range is available immediately; a separate no-optical-drive education version is mentioned without applying its hardware to this consumer record.
