Apple Mac Pro (M2 Ultra) vs Apple Mac Pro (Mid 2010)

Every spec side by side, from each maker's published figures.

Only show differences

Better figure, where one is clearly better

Share comparison

Mac Pro (M2 Ultra) compared with Mac Pro (Mid 2010)

	AppleMac Pro (M2 Ultra)	AppleMac Pro (Mid 2010)
Overview
Released
Released	June 2023	August 2010
Performance
Processor
Processor	Apple M2 Ultra	Intel Xeon W3530, Intel Xeon W3565, Intel Xeon W3680, 2 × Intel Xeon E5620, 2 × Intel Xeon X5650 or 2 × Intel Xeon X5670
CPU cores
CPU cores	24	4, 6, 8 or 12
CPU threads
CPU threads	–	8, 12, 16 or 24
Graphics
Graphics	60-core GPU or 76-core GPU	ATI Radeon HD 5770 (1 GB GDDR5), ATI Radeon HD 5870 (1 GB GDDR5) or 2 × ATI Radeon HD 5770 (1 GB GDDR5 per card)
Memory
Memory	64 GB, 128 GB or 192 GB (better)	3 GB, 6 GB, 8 GB, 12 GB, 16 GB, 24 GB or 32 GB
Storage
Storage	1 TB to 8 TB (better)	512 GB to 2 TB
CPU
CPU	24-core CPU with 16 performance cores and 8 efficiency cores	Standard single 2.8 GHz quad-core Xeon W3530 (Turbo Boost up to 3.06 GHz) or two 2.4 GHz quad-core Xeon E5620 processors (up to 2.66 GHz; eight physical cores and sixteen threads in total). Maker factory upgrades are a single 3.2 GHz quad-core W3565 or 3.33 GHz six-core W3680, or two six-core X5650 at 2.66 GHz or X5670 at 2.93 GHz. Processor count means physical sockets; chip core and thread figures are per processor.
GPU
GPU	60-core or 76-core GPU; additional graphics cards and MPX modules are not supported	ATI Radeon HD 5770 or HD 5870 with 1 GB GDDR5; optional two HD 5770 cards with 1 GB each. Both cards have two Mini DisplayPort outputs and one dual-link DVI port. Graphics memory is per card.
Memory type
Memory type	–	Single-processor systems have four slots and dual-processor systems eight slots for DDR3 ECC SDRAM. Memory runs at 1066 MHz with 2.8/3.2 GHz single and 2.4 GHz dual processors, or 1333 MHz with the six-core processors. Factory order tables list 3, 6, 8, 12 or 16 GB for single-processor systems and 6, 8, 12, 16, 24 or 32 GB for dual systems. The current maker support sheet gives higher supported upgrade limits of 32 and 64 GB respectively using up to 8 GB DIMMs; these are distinguished from the original factory rows.
AI engine
AI engine	32-core Neural Engine	–
Memory bandwidth
Memory bandwidth	800 GB/s	–
Storage type
Storage type	1 TB SSD, configurable to 2 TB, 4 TB or 8 TB; two internal SATA connectors up to 6 Gb/s	Four 3.5-inch cable-free drive bays with independent 3 Gb/s SATA channels and included carriers. Factory choices per bay are a 1 or 2 TB 7200 rpm hard drive with 32 MB cache, or a 512 GB SSD; up to 8 TB with four hard drives or 2 TB with four SSDs. Configurations list one selected drive, with optional additional drives described here. Optional Mac Pro RAID Card has 512 MB cache and 72-hour battery backup; SSDs are not compatible with this card in RAID or Enhanced JBOD mode. Standard 18x double-layer SuperDrive, optional second optical drive.
Media engine
Media engine	Hardware-accelerated H.264, HEVC, ProRes and ProRes RAW; two video decode engines, four video encode engines and four ProRes encode and decode engines	–
Expansion slots
Expansion slots	Six full-length PCIe 4.0 slots (two x16 and four x8); one half-length x4 PCIe 3.0 slot with Apple I/O card installed; up to 300 W auxiliary power through two 75 W six-pin and one 150 W eight-pin connectors	One double-wide PCI Express 2.0 x16 graphics slot and three further full-length slots (one x16 and two x4); 300 W combined maximum. All slots mechanically accept x16 cards. Optional dual- or quad-channel 4 Gb Fibre Channel card.
Display
Screen
Screen	None built in	None built in
Connections
Ports
Ports	8 × Thunderbolt 4, 2 × USB-A, 2 × HDMI, 2 × Ethernet, headphone jack	5 × USB-A, 2 × Ethernet, headphone jack
Ethernet
Ethernet	10 Gb/s (better)	1 Gb/s
External displays
External displays	Up to 8	–
Wi-Fi
Wi-Fi	Wi-Fi 6E	802.11n
Bluetooth
Bluetooth	5.3	2.1 + EDR
Front ports
Front ports	Two Thunderbolt 4 ports on top of the tower or at the front of the rack enclosure	Two USB 2.0 ports, two FireWire 800 ports and a headphone minijack
Back ports
Back ports	Six Thunderbolt 4 ports with DisplayPort, USB 4 up to 40 Gb/s and USB 3.1 Gen 2 up to 10 Gb/s; two USB-A up to 5 Gb/s; two HDMI; two 10 Gb Ethernet supporting 1, 2.5, 5 and 10 Gb/s; 3.5 mm jack with high-impedance headphone support; additional internal USB-A up to 5 Gb/s	Three USB 2.0 ports, two FireWire 800 ports, two independent Gigabit Ethernet ports with jumbo-frame support, optical TOSLINK audio input and output, and analogue stereo line input and output. Graphics outputs vary by card; FireWire and DVI are described here because the main port list has no fields for them. Included keyboard has two additional USB 2.0 ports, excluded from chassis counts.
External displays
External displays	Up to eight displays at 4K 60 Hz, six at 6K 60 Hz or three at 8K 60 Hz; each HDMI port supports one at 8K 60 Hz or 4K 240 Hz, with VRR, HDR and multichannel audio	Up to three displays with one graphics card, or six with two HD 5770 cards. Digital resolution up to 2560 × 1600 and analogue up to 2048 × 1536; optional Mini DisplayPort/DVI/VGA adapters. Multichannel audio through Mini DisplayPort.
Speakers
Speakers	Built-in speaker; HDMI multichannel audio output	Internal speaker and front headphone output; optical and analogue audio input/output
Keyboard and mouse
Keyboard and mouse	Magic Keyboard with Touch ID and Numeric Keypad, Magic Mouse; optional Magic Trackpad	Apple Keyboard with Numeric Keypad and Magic Mouse; optional Apple Wireless Keyboard, Apple Mouse or Magic Trackpad
Design and power
Type
Type	Tower	Tower
Weight
Weight	16.86 kg	–
Width × depth × height
Width × depth × height	218 × 450 × 529 mm	206 × 475 × 511 mm
Operating system
Operating system	macOS	macOS
Size and weight detail
Size and weight detail	Tower with feet is 529 × 218 × 450 mm and 16.86 kg; optional wheels increase height to 557 mm. Rack enclosure is 5U, 220.2 × 482 × 539.5 mm including handles (493.5 mm from fascia), and 17.21 kg; rack depth range 609.6–1,066.8 mm	Standard quad-core configuration weighs 18.1 kg; standard eight-core configuration 18.7 kg. Actual weight varies by configuration and manufacturing process; a shared weight is omitted.
Power supply
Power supply	Built-in; maximum continuous power 1,280 W at 108–125 V or 220–240 V, or 1,180 W at 100–107 V	AC input 100–120 V or 200–240 V, 50–60 Hz; maximum current 12 A at low voltage or 5 A at high voltage
Noise
Noise	–	Apple gives operator-position sound pressure of 26 dB for the 2.8 GHz model and 25 dB for the 2.4 GHz dual-processor model at idle, 26 dB for both during hard-drive access and 37 dB during optical access. Sound power is 3.6 B at idle, 3.7/3.6 B during hard-drive access and 4.6 B during optical access.
Materials
Materials	70% recycled aluminium in the enclosure	Recyclable aluminium enclosure; BFR-free and internal cables PVC-free
Colours
Colours	Silver	–
In the box
In the box	Mac Pro, Magic Keyboard with Touch ID and Numeric Keypad, Magic Mouse, 2 m power lead, 1 m USB-C charge cable; rack mount rails included with the rack enclosure, shipped separately	Mac Pro, power cord, Apple Keyboard with Numeric Keypad, Magic Mouse, USB keyboard extension cable, install/restore DVDs and documentation. Mac OS X Snow Leopard and iLife included; Mac OS X Server and professional applications optional.
