A six-core AM5 processor combining Zen 4 and Zen 4c cores with Radeon 740M integrated graphics.
Cores
6/12
Boost
5 GHz
L3
16 MB
Power
65 W
Socket
AM5
What reviewers say
Reviews find low power consumption and useful integrated graphics for compact everyday PCs and light gaming. The Radeon 740M is substantially slower than the 8600G and 8700G, while the limited graphics-card connection makes this a less attractive processor for a later GPU upgrade. Phoronix particularly likes its efficiency in Linux compilation and CPU-based inference workloads; PCMag finds newer budget rivals stronger for general CPU performance.
Two Zen 4 and four Zen 4c cores; both support simultaneous multithreading. AMD names the family Phoenix; TechPowerUp identifies the smaller monolithic Phoenix 2 die.
Clocks
AMD lists 3.5 GHz overall base; Zen 4 base 4.1 GHz, boost up to 5 GHz; Zen 4c base 3.3 GHz, boost up to 3.7 GHz. CPU multiplier locked in TechPowerUp testing; Precision Boost Overdrive, Curve Optimizer and EXPO supported. Configurable TDP 45–65 W.
Cache
6 MB L2; 16 MB shared L3.
Graphics and AI
Built-in graphics
Yes
Graphics
Radeon 740M; RDNA 3; four graphics cores at 2800 MHz; up to four displays; DisplayPort 2.1 and HDMI 2.1; hardware AV1 encode and decode.
AI engine
No dedicated Ryzen AI NPU (TechPowerUp and Phoronix).
Platform
Socket
AM5
Base power
65 W
Unlocked
No
Memory support
DDR5 UDIMM; two channels; AMD lists maximum DDR5 capacity of 96 GB; ECC requires platform support. Two single- or dual-rank DIMMs: DDR5-5200; four single- or dual-rank DIMMs: DDR5-3600.
PCIe
PCIe 4.0; 14 native lanes, 10 usable; graphics slot limited to ×4 (TechPowerUp). Two native USB4 40 Gbps, two USB 3.2 Gen 2 10 Gbps and one USB 2.0 port.
Chipsets
AMD lists A620, X670E, X670, B650E, B650, X870E, X870, B840 and B850; motherboard firmware support required.
Process
TSMC 4nm FinFET; 137 mm² CPU compute die; one package die.
Cooler
95°C maximum operating temperature. Retail review package includes an air cooler (TechPowerUp); check the exact retail or tray bundle.
