AMD · Threadripper

Ryzen Threadripper PRO 5975WX

Released March 2022

A 32-core Zen 3 workstation processor for sWRX8, with eight-channel DDR4 memory, 128 MB L3 cache and PCIe 4.0.

Model history · 2 models, 2020–2022

2020Ryzen Threadripper PRO 3975WX Compare
2022Ryzen Threadripper PRO 5975WX

Cores: 32/64
Boost: 4.5 GHz
L3: 128 MB
Power: 280 W
Socket: sWRX8

Unlocked

What reviewers say

Reviewers find strong rendering and workstation performance, with a useful improvement over the earlier 32-core PRO model. It often offers a better balance than the 64-core 5995WX for creative applications, but the expensive processor, motherboard and memory make it a specialist choice rather than a mainstream upgrade.

From pugetsystems.com and tomshardware.com

Specifications

Report a wrong or missing spec

Cores and clocks

Cores: 32
Threads: 64
Base clock: 3.6 GHz
Boost clock: 4.5 GHz
L3 cache: 128 MB
Cores: Chagall PRO; Zen 3. Boxed product ID 100-100000445WOF; tray ID 100-000000445. AMD confirmed all five 5000 WX models available in Lenovo ThinkStation P620 systems on 8 March 2022; this is the OEM release, before later standalone retail availability.
Clocks: Precision Boost 2; maximum boost up to 4.5 GHz. Unlocked for overclocking; OEM system restrictions can differ.
Cache: L1 2048 KB; L2 16 MB; L3 128 MB

Graphics and AI

Built-in graphics: No
Graphics: A separate graphics card is required

Platform

Socket: sWRX8
Base power: 280 W
Unlocked: Yes
Memory support: DDR4; eight channels; up to 3200 MT/s. AMD’s launch specification supports up to 2 TB ECC UDIMM, RDIMM or LRDIMM memory; motherboard and system limits can be lower.
PCIe: PCIe 4.0; AMD’s exact-model launch table lists 128 lanes
Process: CPU cores: TSMC 7 nm FinFET
Cooler: AMD’s current specification does not state whether a cooler is included. Maximum operating temperature 95°C.

Pros and cons

Pros

32 cores and 64 threads
Eight-channel memory with ECC support
PCIe 4.0 expansion support

Cons

280 W TDP
Requires a compatible workstation motherboard
No integrated graphics

Closest rivals

Model	Cores	Boost	L3	Power	Socket	Released
AMDRyzen Threadripper 7970X	32/64	5.3 GHz	128 MB	350 W	sTR5	Nov 2023
AMDRyzen Threadripper PRO 7975WX	32/64	5.3 GHz	128 MB	350 W	sTR5	Nov 2023
AMDRyzen Threadripper PRO 5965WX	24/48	4.5 GHz	128 MB	280 W	sWRX8	Mar 2022

Previous model: Ryzen Threadripper PRO 3975WX. Newer model: Ryzen Threadripper PRO 7975WX.

Sources

Photo: Generic Threadripper PRO retail-box artwork from LDLC’s exact boxed 5975WX listing; no individual model label is visible. Original white background and studio shadow retained.
