Apple Keyboard (2003)

Released May 2003

A full-size wired USB keyboard for Macs with a clear enclosure and two accessory ports.

Model history · 3 models, 1998–2003

Specifications

Layout: Full size
Switches: Membrane
Backlight: None
Keys labelled for: Mac
Touch ID: No
Switches: Full-travel standard-pitch membrane keys; the switch type is identified by the mac27 collection.
Layouts: Apple's developer note identifies ANSI, ISO and JIS layout families and 33 localised versions; the ANSI version has 109 keys.
Special keys: Sixteen function keys, six editing keys, inverted-T arrows, numeric keypad and six multimedia controls, including brightness, volume and eject; no power key.

Connects by: Cable
Power: Cable
Receiver: Captive USB-A cable and a bus-powered two-port USB-A hub, according to Apple's eMac developer note.
Works with: USB keyboard included with Apple's May 2003 eMac; Apple's developer note specifies USB HID support.

Materials: White keys in a clear plastic enclosure, identified by iFixit for model A1048.
Colours: White keys and clear enclosure.
In the box: Included with the May 2003 eMac; mac27 documents a separate boxed unit with a USB extension cable.

Model	Layout	Switches	Backlight	Battery	Connects by	Weight	Released
AppleApple Wireless Keyboard (2003)	Full size	Membrane	None	9 months	Bluetooth	–	Sept 2003
AppleApple Pro Keyboard (2000)	Full size	Membrane	None	–	Cable	–	Jul 2000
AppleApple Keyboard with Numeric Keypad (2007)	Full size	Scissor	None	–	Cable	–	Aug 2007
