UltraSharp U2412M

Released July 2011

A 24-inch 16:10 IPS monitor with a 1920 × 1200 panel, DisplayPort, DVI and VGA inputs and a fully adjustable stand.

Size: 24″
Resolution: 1920 × 1200
PPI: 94
Panel: IPS
Refresh: 60 Hz
Brightness: 300 nits
HDR: –
USB-C power: –

What reviewers say

Reviewers liked the useful 16:10 workspace, flexible stand, consistent colours and low input lag. Both found the heavy anti-glare coating visibly grainy, particularly on pale backgrounds. Motion was responsive for ordinary use, though fast movement could show dark overshoot trails. TFTCentral found weaker luminance uniformity; neither review considered it a substitute for a high-refresh gaming display.

From tftcentral.co.uk and pcmonitors.org

Specifications

Report a wrong or missing spec

Display

Screen size: 24″
Resolution: 1920 × 1200 (WUXGA)
Sharpness: 94 pixels per inch
Panel: IPS
Refresh rate: 60 Hz
Response time (grey to grey): 8 ms
Brightness (typical): 300 nits
Contrast ratio: 1,000:1
Colour range: 82% CIE 1976 / 72% CIE 1931
Screen finish: Matte
Shape: Flat
Colour depth: 16.7 million colours, according to Dell.
Response time detail: 8 ms grey-to-grey, according to Dell.
Viewing angles: 178° horizontal and vertical.
Pixel pitch: 0.27 mm.

Connections

Video inputs: DisplayPort 1.1a
USB-C charging: None
USB ports: 4 × USB-A
Speakers: No
DisplayPort detail: One DisplayPort 1.1a input, one DVI-D input with HDCP and one VGA input; no HDMI.
USB hub detail: Four downstream USB 2.0 Type-A ports and one upstream port.
Speaker detail: No integrated speakers; a DC output powers an optional Dell Soundbar.

Design

Stand adjusts: Height, tilt, swivel, pivot
VESA mount: Yes
Weight with stand: 6.24 kg
Height adjustment: 115 mm.
VESA pattern: 100 × 100 mm.
Size with stand: 556 × 180.3 × 398.5–513.5 mm (width × depth × height).
Size without stand: 556 × 64.9 × 361.6 mm (width × depth × height).
Weight without stand: 3.97 kg without stand or cables; Dell lists 6.24 kg with stand and cables.
Controls: Physical front buttons and on-screen display.

Power and support

Power use: 29 W typical; 72 W maximum with maximum luminance, USB and Soundbar active; less than 0.5 W in standby and off modes.
Power supply: 100–240 V AC, 50/60 Hz.
Software: Dell PowerNap.
In the box: Stand, power cable, VGA cable, DVI cable, USB upstream cable and documentation.

Pros and cons

Pros

1920 × 1200 resolution gives extra vertical workspace
Stand adjusts for height, tilt, swivel and pivot
DisplayPort, DVI and VGA support older and newer computers

Cons

No HDMI or USB-C input
USB hub is limited to USB 2.0
No integrated speakers

Closest rivals

Model	Size	Resolution	PPI	Panel	Refresh	Brightness	HDR	USB-C power	Released
AppleLED Cinema Display (24-inch)	24″	1920 × 1200	94	IPS	60 Hz	330 nits	–	–	Nov 2008
DellUltraSharp U2410	24″	1920 × 1200	94	IPS	60 Hz	400 nits	–	–	2009
DellUltraSharp U2415	24.1″	1920 × 1200	94	IPS	60 Hz	300 nits	–	–	2014

Sources

Photo: i.dell.com

Dell U2412M front view with blue screen, exact labelled July2012 catalogue photograph: Dell official brochure, page 5, embedded image Im21.jpg
