Lenovo ThinkPad X201

Lenovo · ThinkPad X

ThinkPad X201

Released March 2010

A 12.1-inch ultraportable ThinkPad with first-generation Core processors, removable batteries and a full-size keyboard.

Model history · 2 models, 2008–2010
  1. 2008ThinkPad X200Compare
  2. 2010ThinkPad X201
Size
12.1″
Display
–
Processor
Intel Core i5
Memory
2 GB – 4 GB
Weight
1.31 kg
Battery
3.4 h

What reviewers say

Reviewers praise the office performance, sturdy construction and comfortable keyboard, with useful endurance from the larger battery. They criticise the small touchpad and lack of modern digital display connections. Notebookcheck finds weak screen contrast and colour coverage, while Laptop Mag considers the screen sufficiently bright for everyday work.

From laptopmag.com and notebookcheck.net

Display

Screen size
12.1″
Resolution
1280 × 800
Brightness
200 nits
Touchscreen
No
Display type
12.1-inch WXGA LCD, 16:10, LED backlight, 250:1 stated contrast
Screen finish
Anti-glare

Performance

Processor
Intel Core i5-540M
CPU cores
2
CPU threads
4
Graphics
Intel HD Graphics
Memory
2 GB or 4 GB
Storage
250 GB to 320 GB
CPU
First-generation Intel Core processors; listed factory configurations are 3249-2EU and 3249-2GU
GPU
Intel HD Graphics integrated in the processor
Memory type
DDR3-1066 PC3-8500; two SO-DIMM sockets, up to 8 GB
Storage type
Removable 2.5-inch SATA drive; listed configurations have 250 GB 5400 rpm and 320 GB 7200 rpm HDDs; optional second drive in UltraBase

Battery and size

Battery life (maker's claim)
Up to 3.4 hours
Weight
1.31 kg
Thickness
35.3 mm
Width × depth
295 × 210 mm
Battery life detail
Four-cell up to 3.4 hours, six-cell up to 6.7 hours, nine-cell up to 11.3 hours; starting weight shown with four-cell battery; six-cell starts at 1.44 kg, nine-cell at 1.60 kg; nine-cell depth is 233.8 mm; body thickness 20.7–35.3 mm
Charger
65 W adapter
Materials
Magnesium alloy
Colours
Black

Connections

Ports
3 × USB-A, Ethernet, SD card slot, headphone jack
Wi-Fi
Intel Centrino Advanced-N 6200 802.11a/b/g/n; optional WiMAX on other configurations
Bluetooth
Bluetooth 2.1
Webcam
Optional 2-megapixel fixed-focus camera
Operating system
Windows
Port detail
Three USB 2.0, VGA, Gigabit Ethernet, RJ-11 modem, separate microphone and headphone jacks, ExpressCard/54, five-format SD reader and UltraBase connector
External displays
VGA up to 2048 × 1536 at 75 Hz; DisplayPort through optional UltraBase up to 2560 × 1600 at 60 Hz
Keyboard
Full-size 89-key spill-resistant keyboard; ThinkLight illuminates the keys
Trackpad
UltraNav multi-touch touchpad and TrackPoint with separate buttons
Speakers
Stereo speakers, 1 W × 2
Microphones
Digital microphone
Biometrics
Swipe fingerprint reader; TPM 1.2

Configurations

ProcessorMemoryStorage
Intel Core i5-540M2 GB250 GB
Intel Core i5-540M4 GB320 GB

Pros and cons

Pros

  • Two memory sockets and replaceable storage
  • Full-size spill-resistant keyboard with TrackPoint
  • Optional UltraBase adds an optical drive and DisplayPort

Cons

  • USB ports are limited to USB 2.0
  • No built-in digital display output
  • Nine-cell battery increases depth and weight

Closest rivals

Model
SizeDisplayProcessorMemoryWeightBatteryReleased
12.1″–Intel Core 22 GB – 3 GB1.35 kg3.3 hAug 2008
12.1″–Intel Core 21 GB1.41 kg3.9 hJun 2007
12.1″–Intel Core Duo T2400512 MB1.43 kg3.9 hFeb 2006

Previous model: ThinkPad X200.

Sources

  1. psrefstuff.lenovo.com/syspool/Sys/PDF/withdrawnbook/ltwbook_2013.pdf
  2. news.lenovo.com/pressroom/press-releases/performance-matters-lenovo-designs-fas…
