UltraSharp U2414H

Released November 2013

A 23.8-inch Full HD IPS monitor with factory-calibrated sRGB colour, DisplayPort daisy chaining, two HDMI inputs and an adjustable stand.

Size: 23.8″
Resolution: 1920 × 1080
PPI: 93
Panel: IPS
Refresh: 60 Hz
Brightness: 250 nits
HDR: –
USB-C power: –

What reviewers say

Reviewers liked the accurate factory sRGB mode, low input lag, clean motion and flexible stand. The lighter anti-glare coating and flicker-free backlight improved everyday use over older UltraSharps. Both encountered colour-signal issues with contemporary Nvidia graphics cards. TFTCentral missed DVI and VGA, while PC Monitors noted IPS glow and the limits of 60 Hz gaming.

From tftcentral.co.uk and pcmonitors.info

Specifications

Report a wrong or missing spec

Display

Screen size: 23.8″
Resolution: 1920 × 1080 (Full HD)
Sharpness: 93 pixels per inch
Panel: IPS
Refresh rate: 60 Hz
Response time (grey to grey): 8 ms
Brightness (typical): 250 nits
Contrast ratio: 1,000:1
Colour range: 96% sRGB
Colour accuracy (Delta E): Below 4
Screen finish: Matte
Shape: Flat
Colour depth: 16.77 million colours, according to Dell.
Response time detail: 8 ms grey-to-grey with overdrive.
Viewing angles: 178° horizontal and vertical.
Pixel pitch: 0.2745 mm.
Calibration: Factory-calibrated to 96% sRGB with average Delta E below 4.

Connections

Video inputs: 2 × HDMI 1.4, 2 × DisplayPort 1.2
USB-C charging: None
USB ports: 4 × USB-A
Speakers: No
HDMI detail: Two HDMI 1.4 inputs with MHL 2.0 support.
DisplayPort detail: One full-size DisplayPort 1.2 and one Mini DisplayPort 1.2 input; separate DisplayPort 1.2 output.
Daisy chaining: DisplayPort 1.2 MST output.
USB hub detail: Four downstream USB 3.0 ports and one upstream port; one downstream port supports BC 1.2 charging.
Audio out: Audio line output; Dell specifies it is not for headphones.
Speaker detail: No integrated speakers; optional Dell Soundbar.

Design

Stand adjusts: Height, tilt, swivel, pivot
VESA mount: Yes
Weight with stand: 5.76 kg
Height adjustment: 130 mm.
Tilt: 6.5° forward to 22° backward.
Pivot: 90° in either direction.
VESA pattern: 100 × 100 mm.
Size with stand: 539.1 × 185 × 355.8–485.8 mm (width × depth × height).
Size without stand: 539.1 × 45.6 × 321.1 mm (width × depth × height).
Weight without stand: 3.61 kg without stand or cables; main 5.76 kg includes stand and cables.

Power and support

Power use: 16 W typical; 74 W maximum with maximum luminance and USB active; below 0.5 W in standby and off modes.
Power supply: 100–240 V AC, 50/60 Hz.
In the box: Stand, cable cover, power cable, Mini DisplayPort-to-DisplayPort cable, USB upstream cable, calibration report and documentation.

Pros and cons

Pros

Factory-calibrated sRGB colour
DisplayPort supports daisy chaining
Height, tilt, swivel and pivot adjustment

Cons

60 Hz refresh rate
No USB-C charging
No DVI or VGA input

Closest rivals

Model	Size	Resolution	PPI	Panel	Refresh	Brightness	HDR	USB-C power	Released
AppleLED Cinema Display (24-inch)	24″	1920 × 1200	94	IPS	60 Hz	330 nits	–	–	Nov 2008
AppleCinema HD Display (23-inch, ADC)	23″	1920 × 1200	98	IPS	–	200 nits	–	–	Apr 2002
AppleCinema HD Display (23-inch, DVI)	23″	1920 × 1200	98	IPS	60 Hz	270 nits	–	–	Jul 2004

Sources

Photo: i.dell.com

Two Dell U2414H monitors in portrait orientation with panorama across physical displays: Dell official brochure, page 1, embedded image Im0.jpg
